Complete stainless steel Horizontal Pressure Steam Sterilizer horizontal design optimizes space utilization and facilitates uniform steam distribution within the chamber. equipped with precise controls for managing temperature, pressure, and sterilization cycles, ensuring effective pathogen elimination. inclusion of a built-in printer allows for the automatic documentation of sterilization cycles. This feature enhances traceability and provides a record of each sterilization process. The sterilizer is suitable for a range of applications, including medical and laboratory settings, due to its horizontal design and stainless steel construction. The sterilizer features an efficient water management system to ensure steam generation during the sterilization process.
● Automatially controlled sterilizing process, easy to operate.
● With drying function, suitable for medical dressing drying.
● With over-temperature, over-pressure auto-protect.
● The door can not be opened until the pressure in the chamber is reduced to 0.027MPa. And the unit can not be started if the door doesn't close well.
● The safety valve will be open automatically when the inner pressure is over 0.24MPa and the steam would be exhausted in the water tank.
● Automatically cut off the power if the water leak happens, and alarm in the meanwhile.
● Fully stainless steel structure.
● With printer.
MODEL/Technical Data | WS-150YDD | WS-200YDD | WS-280YDD |
Sterilizing chamber volume | 150L | 200L | 280L |
Φ440×1000mm | Φ515×1000mm | Φ600×1000mm | |
Working pressure | 0.22Mpa | ||
Working temperature | 134℃ | ||
Temperature adjust range | 40-134℃ | ||
Time for sterilization | 0-99min | ||
Time for drying | 0-99min | ||
Heat average | ≤±2℃ | ||
Power | 9kw/380V 50Hz | 9kw/380V 50Hz | 12kw/380V 50Hz |
Dimension(mm) | 1400×650×1820 | 1400×750×1700 | 1520×910×1900 |
Transport dimension(mm) | 1560×860×1820 | 1560×910×1880 | 1680×1060×2050 |
G.W/N.W | 430/340kg | 436/350Kg | 570/462Kg |
